Fastest Connection: Thunderbolt Technology
By employing the new Thunderbolt technology, the PAIR Thunderbolt RAID System can now be accessed like the speed of light, at a maximum of 10Gbit per second! The Thunderbolt technology combines PCI express and display port features into one single interface, providing two channels of 10 Gbps throughput going in both directions on the same connector. With the Thunderbolt Technology, the PAIR Thunderbolt RAID System allows extreme backups and video/photo streaming performances up to 20 times faster than USB 2.0 and up to 12 times faster than FireWire 800.
Data Security While on the Road: RS-S2T Thunderbolt RAID System
The PAIR Thunderbolt RAID System, a 2-Bay RAID System for 2.5-inch hard drives and SSD, is designed for professional video/audio and content creation applications. It is light for travel, perfect for mobile users who also crave heavy RAID supervision! Provided by the PAIR Thunderbolt RAID System, the RAID modes can be set using the intelligible GUI provided by package CD or host OS. The colored LEDs indicate immediate system status and the two Thunderbolt ports provide daisy-chain for multiple-device connections up to 6 Thunderbolt devices, including any devices compatible with the mini-DisplayPort.
Perfect External Boot-up System:SSD vs. Hard Drive
With a slim yet sturdy housing, the PAIR Thunderbolt RAID System can securely seal away any two 9.5mm or 12.5mm 2.5-inch hard drives or SSDs (solid-state/electronic drives) and shield them from accidental falls! By using the bundled black "Slip Bag", the PAIR Thunderbolt RAID System can slide into any travel bag! When SSDs are inserted into the PAIR Thunderbolt RAID System, the System can be utilized for external boot up with much faster read/write speeds efficiency. When a SSD is combined with a traditional hard drive under JBOD, the PAIR Thunderbolt RAID System can become an external boot-up unit while still having extra room for data storage. The PAIR Thunderbolt RAID System is flexible by utilizing the best features in both SDDs and/or hard drives, and provides quicker transfer rates with the Thunderbolt technology.
Thunderbolt Cable: Bundled WITH the Package
The Thunderbolt cable is bundled with the PAIR Thunderbolt RAID System; thus, one single cable (electrical) can link all the desired devices together! Furthermore, when bus-powered device(s) are connected (after the PAIR Thunderbolt RAID System), dual-channeled power delivery and bi-directional data transfer are available using the Thunderbolt cable!
Thunderbolt and the Thunderbolt logo are trademarks of Intel Corporation in the US and other countries.
|
|
Connects via Thunderbolt ports, up to 10 Gbps data transfer rate
Supports current 9.5mm or 12.5mm SATA compliant hard drives and SSDs
Supports RAID tasks, including: JBOD (non-RAID), RAID 0 (Striping), and RAID 1 (Mirroring)
Provides daisy-chain with increased speed and flexibility
Monitors system status via LED indicators or GUI
Configures RAID modes easily using GUI or host OS (Disk Management/Disk Utility)
Bundles Thunderbolt cable with the RAID System
Comes with a black Slip Bag, easy to carry with generous protection
|
|
|
| Specifications |
Download |
| HDD Support |
2.5-inch SATA or SSD
|
| Connector |
Thunderbolt port x 2
|
| Data Transfer Speed |
Up to 10 Gbps
|
| RAID mode |
JBOD (None RAID), RAID 0, RAID 1
|
| LED Indicator |
Power / Connect / Health / Access / Rebuild
|
| System Material |
Aluminum case with plastic parts
|
| Power Supply |
Input: AC100~240V; Output: DC +12V/1.5A
|
| Dimension |
155 (L) x 155 (W) x 25 (H) mm
6.1 (L) x 6.1 (W) x 1 (H) inch
|
| Weight (w/o HDD) |
280 g
0.62 lbs
|
| |
|
|
|
 |
|
|
| RAID MASTER Rev.517 for MAC |
| The RAID MASTER (GUI) is the RAID configuration for SMART Thunderbolt RAID System (RS-M4T, RS-M2T, RS-S2T). Do not apply it to the FireWire RAID Systems. |
|
|
|
|
|
|
|
